Water coupling AG, female with hose tail

Application:

AG coupling housing suitable for i.a. connection of water hoses.
Nito compatible.

Construction:

The coupling housing is designed to achieve a high level of function and a long service life.

Quality:

  • Housing, spring, and balls made of stainless steel
  • Nitrile rubber gasket

Temperature:

The temperature ranges up to +90°C.
Working pressure 25 bar.

Download data sheet
Item number Nominal dim.
inch
Ø ID hose
mm.
Net weight
kg.
Base unit Quantity
0280009102 1/2" 13,0 0,140 PCS
0280009102E 1/2" 13,0 0,140 PCS
0280009132 3/4" 20.0 0,140 PCS
0280009132E 3/4" 20,0 0,140 PCS
Subject to incorrect product data, variations in images/videos, and price and exchange rate changes.
