DIN Clamp liner

Internal surface roughness of R 0.8 µ and provided with a batch number.
Designed with collar for welding on stainless steel dairy pipes.

Made of AISI 316L / EN 1.4404 stainless steel.

Standard DIN 32676.

Download data sheet

Item number	Nominal dim. mm.	A dia. mm	ID Ø dia. mm.	OD Ø dia. mm.	Length B mm	Net weight kg.	Base unit
0101440101	10,0	34,0	10,0	13,0	18,0	0,060	PCS
0101440151	15,0	34,0	16,0	19,0	18,0	0,060	PCS
0101440201	20,0	34,0	20,0	23,0	18,0	0,060	PCS
0101440251	25,0	50,5	26,0	29,0	21,5	0,070	PCS
0101440321	32,0	50,5	32,0	35,0	21,5	0,050	PCS
0101440401	40,0	50,5	38,0	41,0	21,5	0,050	PCS
0101440501	50,0	64,0	50,0	53,0	21,5	0,070	PCS
0101440651	65,0	91,0	66,0	70,0	28,0	0,17	PCS
0101440801	80,0	106,0	81,0	85,0	28,0	0,170	PCS
0101441001	100,0	119,0	100,0	104,0	28,0	0,240	PCS
0101441251	125,0	144,4	125,0	129,0	28,0	0,320	PCS
0101441252	125,0	155,0	125,0	129,0	28,0	0,470	PCS
0101441501	150,0	167,0	150,0	154,0	28,0	0,500	PCS
0101441502	150,0	183,0	150,0	154,0	28,0	0,550	PCS
0101442001	200,0	217,4	200,0	204,0	28,0	0,700	PCS
0101442002	200,0	233,5	200,0	204,0	28,0	0,750	PCS
0101442501	250,0	268,0	250,0	254,0	28,0	0,900	PCS
0101443001	300,0	319,0	300,0	304,0	28,0	0	PCS
