Clamp nut, DIN, 11864-3, series B

Follows the standard DIN 11864-3, series B.

Made of stainless steel AISI 316L.

Download data sheet

Item number	Nominal dim. mm.	D1 dia. mm.	D2 dia. mm.	Dia. mm. D3	Length L mm.	Installation dim. L1 mm.	Net weight kg.	Base unit
0102282013B	13,5	10,3	13,5	34,0	39,5	26,0	0,05	STK.
0102282017B	17,2	14,0	17,2	34,0	39,5	26,0	0,05	STK.
0102282021B	21,3	18,1	21,3	34,0	40,5	26,0	0,09	STK.
0102282026B	26,9	23,7	26,9	50,5	40,0	30,0	0,09	STK.
0102282033B	33,7	29,7	33,7	50,5	45,5	30,0	0,09	STK.
0102282042B	42,4	38,4	42,4	64,0	45,5	30,0	0,14	STK.
0102282048B	48,3	44,3	48,3	64,0	46,5	30,0	0,180	PCS
0102282060B	60,3	56,3	60,3	91,0	58,5	40,0	0,28	STK.
0102282076B	76,1	72,1	76,1	106,0	60,0	40,0	0,34	STK.
0102282088B	88,9	84,3	88,9	119,0	62,5	40,0	0,37	STK.

Subject to incorrect product data, variations in images/videos, and price and exchange rate changes.
