Valve disk, AWH butterfly valve, DIN

Application:

Spare part for AWH butterfly valve, DIN standard.

Quality:

Made of stainless steel EN 1.4404 / AISI 316L.

Download data sheet

Item number	Nom. dim. - DN	Dia. mm. D3	Bredde mm. - B1	Length L mm.	Weight/pcs. kg.	Base unit
0520320010	10	10,0	9,5	47,0	0,03	PCS
0520320015	15	16,0	9,5	49,5	0,03	PCS
0520320020	20	20,0	9,5	60,5	0,04	PCS
0520320025	25	26,0	9,5	80,0	0,05	PCS
0520320032	32	32,0	9,5	87,5	0,06	PCS
0520320040	40	38,0	9,5	93,5	0,10	PCS
0520320050	50	50,0	9,5	111,0	0,15	PCS
0520320065	65	66,0	9,5	128,0	0,24	PCS
0520320080	80	81,0	9,5	144,0	0,39	PCS
0520320100	100	100,0	9,5	164,0	0,63	PCS

Subject to incorrect product data, variations in images/videos, and price and exchange rate changes.
