Camlock female coupling, type B, polypropylene

Application:

Camlock female coupling, type B, polypropylene (PP) with hose connection is a simple and robust no-maintenance coupling that can be assembled to a tight coupling without using tools. It is suitable for various liquid and gas lines.

Construction:

  • Made from black polypropylene with stainless steel cam arms and pins
  • Smooth with full passage, ensures optimal flow of liquids and gasses
  • Excellent chemical resistance to aggressive chemicals and solvents

Quality:

The coupling comes in black polypropylene but is also available in other materials.

Complies with the requirements from DIN 2828.

Gasket:

As standard, the gasket comes in NBR, but it is also available in other materials such as Viton and EDPM.

Safety factor:

3 times working pressure.

Temperature:

Temperature range from -20°C to +90°C.

Download data sheet
Item number Nom. dim. - DN Connection
RG
C dia.
mm.
D dia.
mm.
Length L
mm.
Working pressure
bar
Net weight
kg.
Base unit Quantity
0472562012 DN12 1/2" 15,0 54,0 10,0 0,05 PCS
0472562020 DN20 3/4" 18,0 54,0 10,0 0,07 PCS
0472562025 DN25 1" 24,0 60,0 10,0 010 PCS
0472562032 DN32 1 1/4" 33,0 70,0 10,0 0,16 PCS
0472562040 DN40 1 1/2" 37,0 72,0 10,0 0,17 PCS
0472562050 DN50 2" 49,0 82,0 10,0 0,22 PCS
0472562065 DN65 2 1/2" 63,0 85,0 -10,0 0,25 PCS
0472562080 DN80 3" 76,0 89,0 10,0 0,35 PCS
0472562100 DN100 4" 98,0 95,0 10,0 0,67 PCS
Subject to incorrect product data, variations in images/videos, and price and exchange rate changes.
